▎Smart charger with multi-protection functions
▎ Suitable for 48V lithium batteries
▎ Voltage data visualization
▎ Charging indicators
▎ Wide operating temperature range
▎Build-in Reverse polarity protection
INQUIRY
Share it：
▎ Features
▎ Technical Parameters
Model
YL-CESK546
Name
Lithium battery charger / Power supply
Main parameters
Max. output power
2000W
Input voltage
220VAC
Output voltage
54.6V+-0.2VDC
Output current
30A+-0.2A
Storage temperature
-40~70℃
Working temperature
-10~40℃
Dimension
L*W*H=300×175×90mm
AC Terminal
Customized
DC Terminal
Cable length
Input parameters
Rated input voltage
220Vac
Input voltage range
180 ~ 260Vac
AC input voltage frequency
50～60 Hz
Output characteristic
CC(constant current)
≤54.6Vdc, 30A
CV(constant voltage)
54.6Vdc, 30A↓
Power efficiency
≥85%
Protection functions
Over voltage protection
Software over voltage protection: The charger software limits the maximum output voltage to a level suitable for the connected battery system.
Over temperature protection
Current limiting protection
Short circuit protection:
Short circuit protection should be automatically recovery after remove the condition.
Reverse polarity protection:
When output wires are reversely connected to the battery the charger will not operate and will work normally when DC wires are correctly connected.
Charging indicator
Power on
LED1: Red
Charging
LED2: Red
Fully charged
LED2: Green
Charging Voltage Display
YES
Charging Current Display
