● Standard: QC / T 1037 standard
● Rated Voltage：AC 1000V/DC 1500V
● Operating Temperature：-40℃~125℃ / 150℃
● Fire Rating：VW-1
Product diagram
| Specification | Conductor | Insulation |
| Cross-sectional area(mm²) | Outer diameter(mm) | Outer diameter(mm) |
| Nominal | Max. | Max. |
| 10 | 4.5 | 6.5 |
| 16 | 5.8 | 8.3 |
| 25 | 7.2 | 10.4 |
| 35 | 8.5 | 11.6 |
| 50 | 10.5 | 13.5 |
| 70 | 12.5 | 15.5 |
| 95 | 14.8 | 18.0 |
| 120 | 16.5 | 19.7 |
